2642040000 - 57.15mm Clamping Yoke Connector, 16 Poles, RoHS & UL Certified (Pack of 72)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/16/90 SN GN BX, your ideal solution for efficient field connections This product features a clamping yoke connection method and offers a compact size, measuring 5715 mm in length with a 381 mm pitch It supports connections for up to 16 poles with a wire outlet direction set at 90° Engineered for safety and reliability, it complies with RoHS regulations and holds UL certification.

It accommodates wire cross-sections from 02 mm² to 15 mm² (AWG 30 to AWG 16), making it versatile for various applications Constructed from durable copper alloy for the contacts and PA insulating material, this component is built to withstand temperatures from -40 °C to +105 °C Packed conveniently in boxes of 72, this product is perfect for your connection needs.

Features and Benefits:

•Includes 72 items per order.

•Supported clamping range from 0.2 mm² to 1.5 mm².

•Designed for ratings of up to 8 A at 300 V.

•Constructed with copper alloy contacts and PA insulating material.

•Adaptable to different types of wire connections with various stripping lengths.

•Field connection applications.

•OMNIMATE basic product compatibility.

Specifications:
