2641680000 - 3.5mm 18-Pole Connector with RoHS Compliant Insulation (Pack of 168)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 350/18/90G 35SN GN BX, a top-tier connector engineered for dependable board connections With a versatile THT solder connection mounting type and a pitch of 35 mm, this connector features a configuration of 18 poles, each equipped with a solder pin measuring 35 mm in length Constructed from a lightweight pale green insulating material made of PA GF, this product adheres to RoHS regulations and boasts a UL 94 flammability rating of V-0, ensuring safety and compliance.

It operates flawlessly in storage temperatures between -40 °C and 70 °C, and can function at temperatures as high as 105 °C With a rated voltage of 320 V as per IEC standards and a current rating of 8 A, this connector meets rigorous UL and CSA standards, making it a reliable choice for your electronic needs.

Features and Benefits:

•Complies with RoHS without exemption.

•Suitable for long-term storage under specified conditions.

•Only compatible with OMNIMATE basic products.

Specifications:
