2640460000 - 3.5mm Pitch Copper Alloy Clamping Yoke Terminal, 10 Poles (Pack of 112)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 350/10/270 SN GN BX, an exceptional component for effortless field connections, featuring a reliable clamping yoke connection method This unit has a pitch size of 35 mm and is capable of accommodating 10 poles, providing a conductor outlet at a 270-degree angle With a maximum voltage rating of 320 V and a current capacity of 8 A, it is designed to support wire sizes from AWG 30 to AWG 16.

Constructed from a durable copper alloy and featuring PA insulating material, it guarantees outstanding performance while meeting essential environmental criteria such as RoHS compliance.

Features and Benefits:

•Clamping range supports wire sizes from 0.2 mm² to 1.5 mm².

•Rated for up to 25 plugging cycles.

•Tightening torque specifications ensure secure connections.

Specifications:
