2640260000 - 9-Pole Clamping Yoke Connection Component, 0.2-1.5 mm² (Pack of 150)

Description:

Introducing the CPS 350/09/180 SN GN BX, a robust solution for field connections featuring a reliable clamping yoke mechanism This component accommodates wire sizes from 02 to 15 mm², ensuring versatility for various applications Proudly compliant with RoHS regulations and UL certified, it guarantees quality for both voltage and current needs The rated voltage spans from 160 V to 320 V, depending on contamination levels and surge voltage class, while maintaining a consistent rated current of 8 A.

Its pale green insulating material adds a touch of uniqueness, and the component is designed for easy installation with a single row layout, incorporating 9 poles for efficient connectivity.

Features and Benefits:

•Field connection type.

•Clamping yoke connection method.

•180° conductor outlet direction.

•Single row design with 9 poles.

•Durable insulating material (PA).

•UL 94 flammability rating of V-0.

•Plugging durability of 25 cycles.

•Min and max clamping range accommodates various wire sizes.

•Suitable for general electrical connections in various fields.

Specifications:
