2646040000 - 5mm Pitch Connector with 22 Poles, Durability Rated up to 105°C (Pack of 60)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Ensure reliable board connections with the OMNIMATE Signal connector, order number 2646040000 This RoHS-certified component boasts IEC ratings of 630 V and 15 A, making it a robust choice for various applications Featuring a 5 mm pitch and 22 poles, each equipped with a 39 mm long solder pin, this connector allows for efficient THT soldering techniques Constructed with PA GF for insulation and durable tinned copper alloy contacts, it stands up to temperatures ranging from -40 °C to +105 °C, ensuring excellent performance in diverse conditions.

Features and Benefits:

•Compliant with RoHS without exemptions.

•No SVHC above 0.1 wt%.

•Insulating material rated UL 94 V-0.

•Components can withstand high temperatures and humidity.

Specifications:
