2645660000 - 5mm Pitch 3-Pole Connector with 90° Elbow, Pale Green (Pack of 300)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 500/03/90 39SN GN BX connector, perfect for your board connection needs with a 5 mm pitch designed specifically for THT soldering This connector features a 90° elbow for efficient cable management and boasts three poles, each equipped with a solder pin measuring 39 mm in length Constructed from PA GF insulating material with a pale green hue (RAL 6021), this component can operate safely at temperatures up to 105 °C.

Plus, it adheres to RoHS regulations, ensuring that it meets environmental compliance standards.

Features and Benefits:

•Compliant with ROHS regulations.

•Insulating material group I.

•UL 94 flammability rating V-0.

•Compatible only with OMNIMATE basic products.

•Rated current 15 A.

•Rated voltage 630 V.
