2645350000 - 19-Pole 5mm Pitch THT Connector with 90° Elbow (Pack of 65)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CH 500/19/90F 39SN GN BX, an expertly crafted connector designed for robust board connectivity through a THT solder method This component features a 5 mm pitch and is equipped with a 90-degree outgoing elbow It comprises 19 poles, each housing a solder pin with a length of 39 mm Packaged conveniently in a box, this product adheres to RoHS standards with an exemption and holds various certifications, including UL, ensuring its reliability and safety in use.

Features and Benefits:

•Includes 19 poles with one solder pin for each.

•Dimensions are compliant with IEC and UL standards.

•Constructed with PA GF insulating material.

•Contact materials use Cu-alloy for durability.

•Outfitted with a tinning type that is matte.

Specifications:
