2644460000 - 22-Pole 5mm Pitch Field Connector, 630V, RoHS Compliant (Pack of 18)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the OMNIMATE Signal series field connection component, engineered to support voltages up to 630 V and currents up to 18 A It accommodates wire cross-sections from 02 mm² to 4 mm², making it versatile for various connections Weighing in at 451 g, each unit comes packaged in a box This component adheres to RoHS standards and includes necessary environmental compliance exemptions It features a reliable clamping yoke connection method with a compact pitch of 5 mm, arranged in 22 poles in a single row.

The terminals are optimized for wire stripping lengths of 7 mm, and the recommended tightening torques range from 05 Nm to 055 Nm Crafted from sturdy PA insulating material, this component is offered in a soft pale green hue, closely resembling RAL 6021 It is suitable for a diverse selection of cables, accommodating both stranded and solid wire types.

Features and Benefits:

•Field connection capability.

•Single row design with 22 poles.

•Clamping yoke connection method.

•Low clamping range from 0.2 mm² to 4 mm².

•Suitable for various wire types, including flexible and stranded wires.

•Operating temperature range from -40 °C to 105 °C.

Specifications:
