2644400000 - RoHS Compliant Clamping Yoke, 630V, for 0.2-4mm² Wires (Pack of 24)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 500/16/270 SN GN BX, an essential clamping yoke connection component ideal for field applications This device meets multiple standards, including IEC and UL, supporting a maximum voltage rating of 630 V and a current capacity of up to 18 A It accommodates a variety of wire sizes from 02 to 4 mm² (AWG 26 to AWG 14) with an optimal strip length of 7 mm Compatible with standard-sized screwdrivers, this component ensures ease of use.

Additionally, it complies with RoHS regulations and is constructed from high-quality PA for insulation and copper alloy for the contacts, making it reliable for diverse installation scenarios.

Features and Benefits:

•Single-row design with a total of 16 poles.

•Plugging cycles rated up to 25 cycles.

•Offers min and max tightening torque specifications.

•Insulation resistance rated at 500 MΩ.

•Compatible with OMNIMATE basic products.

•Field connection for electrical installations.

Specifications:
