2642950000 - Compact 12-Pole Clamping Yoke Connector, 3.81mm Pitch (Pack of 72)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the CPS 381/12/270F SN GN BX, a component from the OMNIMATE basic series tailored for reliable connectivity This model features a 381 mm pitch and a unique clamping yoke design that allows for conductor outlet at a 270° angle With 12 poles and a compact build, it requires a stripping length of 65 mm Tightening is efficient with a tensile strength ranging from 022 Nm to 025 Nm Capable of connecting wire cross-sections between 0.

2 mm² and 15 mm², this product meets various safety standards, including RoHS and UL, making it an excellent choice for high-performance applications.

Features and Benefits:

•Compliant with RoHS.

•Suitable for long-term storage at an average temperature of 50 °C and 70% humidity for up to 36 months.

•Compatible only with OMNIMATE basic products.

•Rated current and voltage specifications defined for both IEC and UL standards.

Specifications:
