2642900000 - RoHS Compliant 3.81mm Connector for 0.2-1.5mm² Wires (Pack of 108)

Description:

Introducing the CPS 381/07/270F SN GN BX connector, crafted in line with RoHS guidelines and UL certifications, making it ideal for a range of wire connections This robust connector offers a voltage capacity of 320 V and can handle a current rating of 8 A, accommodating wire dimensions from 02 to 15 mm², equivalent to AWG 30 to AWG 16 Designed primarily for field connections, it includes a user-friendly clamping yoke mechanism and features a 3.

81 mm pitch Its unique 270-degree conductor outlet direction allows for versatile installation, while a maximum tightening torque of 025 Nm ensures secure fittings Each box contains connectors that weigh just 633 g, and they are produced in accordance with environmental regulations Constructed with a blend of insulating and contact materials, this connector can effectively operate in temperatures reaching up to 105 °C, making it both reliable and efficient for various applications.

Features and Benefits:

•Compliant with RoHS and UL standards.

•Designed for field connection applications.

•Accommodates various wire sizes from 0.2 mm² to 1.5 mm².

•Includes a clamping yoke connection method.

•Resistant to temperature variations with a maximum operation temperature of 105 °C.

•Constructed from durable PA insulating material.

•Features a compact design with a 270-degree outlet direction.

•Field connections in electrical applications.

Specifications:
