2642840000 - 20-Pole 3.81mm Clamping Connector with Tinned Copper Alloy (Pack of 48)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/20/180F SN GN BX, a versatile solution for field connections This model features a clamping yoke design, operating with a pitch of 381 mm to support up to 20 poles with conductors oriented at a 180-degree angle It can accommodate conductor sizes between 02 mm² and 15 mm², adhering to stringent standards such as RoHS and UL for safety and compliance Crafted from tinned copper alloy for reliable contacts and engineered with a PA insulating material that withstands temperatures of up to 105 °C, this product ensures durability under demanding conditions.

With capabilities for a maximum plugging and pulling force of 12 N, it offers an impressive longevity with up to 25 plugging cycles This item meets various environmental regulations and is conveniently packaged in a box for safe storage and easy transport.

Features and Benefits:

•Compliant with RoHS exemption 6c.

•Suitable for long-term storage up to 36 months at 50 °C and 70% humidity.

•Compatible only with OMNIMATE basic products.

Specifications:
