2642800000 - 3.81mm 16-Pole Wire Connector with 180° Clamping Yoke (Pack of 66)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Experience reliable field connections with the CPS 381/16/180F SN GN BX terminal block Designed with a compact 381 mm pitch, it allows for a conductor outlet direction of 180 degrees and supports up to 16 poles This robust component is rated for 320 V and a maximum current of 8 A, making it compatible with wire sizes ranging from 02 mm² to 15 mm² Crafted from high-quality PA insulating material and featuring copper alloy contacts, it ensures durability and compliance with RoHS standards.

With its impressive operational temperature range of -40 °C to 105 °C, the CPS terminal block is a dependable choice for a variety of applications while maintaining optimal system performance.

Features and Benefits:

•Field connection type with clamping yoke connection method.

•Single row design.

•Rated for up to 25 plugging cycles.

•Compatible only with OMNIMATE basic products.

Specifications:
