2642760000 - 41.91mm Clamping Yoke 12-Pole Connector, 180° Outlet (Pack of 84)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/12/180F SN GN BX, an ideal solution for field connections utilizing a reliable clamping yoke connection method This component boasts a 381 mm pitch across 12 poles, ensuring efficient performance With a compact size of 4191 mm in length, it allows for a conductor outlet at a 180° angle It accommodates wire connections ranging from 02 mm² to 15 mm², making it versatile for various applications.

Meeting environmental regulations, this product comes with UL approval and is RoHS compliant Packaged in a secure box, it weighs only 98 grams, making it lightweight and easy to handle.

Features and Benefits:

•180° conductor outlet direction.

•Single row with 12 poles.

•Packaging indicates a box with product dimensions.

•Compliant with RoHS exemption.

•Compatibility with OMNIMATE basic products.

Specifications:
