2642730000 - OMNIMATE 9-Pole Connector, PA Material, AWG 30-16 Compatibility (Pack of 105)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the OMNIMATE basic series field connection component, expertly engineered to support a wide range of wire connections from AWG 30 to AWG 16, accommodating conductor sizes between 02 and 15 mm² With an operating capability of 320 V and 8 A per IEC standards, this component guarantees reliable electrical performance Constructed from durable PA material, it comes in a pale green hue that aligns with RAL 6021 standards.

This connector offers flexibility with various stripping lengths and maintains precise tightening torque specifications, withstanding maximum temperatures of 105 °C Ideal for clamping yoke connections, it features a single-row configuration housing 9 poles.

Features and Benefits:

•Clamping yoke connection method.

•Conductor direction at 180°.

•9 poles in a single row.

•Insulating material: PA.

•UL 94 flammability rating of V-0.

•Compatible with OMNIMATE basic products only.

•Plugging cycles rated at 25.

Specifications:
