2642610000 - 90° Clamping Yoke Connection, 3.81mm Pitch, AWG 30-16 (Pack of 56)

SKU: SKU: 2642610000 Download PDF

Select a Variant:

2642610000 - 90° Clamping Yoke Connection, 3.81mm Pitch, AWG 30-16 (Pack of 56)

SET THE QTY:

Now $744.70 Web pricing policy

~~BEFORE $0.00~~ Now $744.70 Web pricing policy

Sold out

Shipping calculated at checkout.

IN STOCK
Shipping Available

Free shipping on orders above $1000. *Wires and cables only.

View full details

Product Information Resources Reviews

Product Information

Description:

The CPS 381/16/90F SN GN BX connector is engineered for dependable field connections featuring clamping yoke technology It supports wire sizes ranging from 02 mm² to 15 mm² and accommodates conductor types from AWG 30 to AWG 16 With a 90° outlet for easy installation and a compact pitch of 381 mm, this connector is both versatile and efficient It can withstand an operating temperature of up to 105 °C and a maximum storage temperature of 70 °C.

This product also adheres to RoHS environmental standards, making it a great choice for eco-friendly projects.

Features and Benefits:

•Field connection type ensures efficient wiring.

•Suitable for a variety of conductor sizes and types.

•Compact design with a 90° outlet for space-saving.

•RoHS compliant, supporting environmental regulations.

•Rated for a voltage of 320 V and a current of 8 A.

Specifications:

Order No.	2642610000
IEC Rated Voltage	320 V
IEC Rated Current	8 A
Wire Connection Method	Clamping yoke connection
Number of Poles	16
Pitch	3.81 mm
Stripping Length	6.5 mm
Tightening Torque (min)	0.22 Nm
Tightening Torque (max)	0.25 Nm
Plugging Cycles	25
Clamping Range (min)	0.2 mm²
Clamping Range (max)	1.5 mm²
Net Weight	13.44 g
Insulating Material	PA
Color	Pale green
Flammability Rating	V-0
Storage Temperature (min)	-40 °C
Storage Temperature (max)	70 °C
Operating Temperature (max)	105 °C
