2642410000 - 3.81mm Pitch RoHS Connector with 270° Outlet Direction (Pack of 72)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

The CPS 381/15/270 SN GN BX connector is engineered for a variety of electrical connection requirements Compliant with RoHS regulations and various certification standards including UL, this connector features a clamping yoke connection With a 381 mm pitch and a 270° conductor outlet configuration, it supports wire sizes from 02 mm² to 15 mm² This device can handle rated currents up to 8 A and operates reliably at voltages of 320 V, making it a versatile choice for your electrical needs.

Features and Benefits:

•Compliant with RoHS and REACH regulations.

•Made from durable materials including copper alloy and PA insulation.

•Designed for field connections with a practical stripping length of 6.5 mm.

•Ensures high reliability with a maximum plugging cycle of 25.

•Compact design with small dimensions for efficient installation.

•Used in various electrical connection applications within the OMNIMATE system.

Specifications:
