2642070000 - 19-Pole 3.81mm Clamping Connector with 90° Outlet (Pack of 56)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the CPS 381/19/90 SN GN BX connector, crafted for reliable field connections with its clamping yoke design This single-row component features 19 poles and offers a pitch measurement of 381 mm With a conductor outlet angle of 90°, it accommodates wire sizes from 02 mm² to 15 mm² Adhering to essential safety guidelines, it complies with ROHS and UL standards for operating voltages up to 300 V and currents up to 8 A.

Each package contains 56 connectors, making it a practical choice for your electrical needs.

Features and Benefits:

•Field connection capable through clamping yoke connections.

•Complies with ROHS and UL standards.

•Suitable for a range of conductor sizes from 0.2 mm² to 1.5 mm².

•Can accommodate specific configurations for pin series and screw tightness.

Specifications:
