2641670000 - 3.5mm 17-Pole Signal Connector with 90-Degree Elbow (Pack of 192)

Description:

Introducing the CH 350/17/90G 35SN GN BX, a precision-engineered component from the OMNIMATE Signal product line This item is RoHS compliant and bears a UL certification, ensuring adherence to safety and environmental standards Operating efficiently at a voltage of 320 V with a current rating of 8 A, it comes neatly packaged in a box Weighing in at just 476 grams, this board connection solution features a 3.

5 mm pitch and a 90-degree angled elbow for optimal installation The component boasts 17 poles, each equipped with a 35 mm solder pin Crafted from PA GF in a subtle pale green hue reminiscent of RAL 6021, the insulating material meets UL 94 V-0 flammability standards Constructed from durable copper alloys with a matte tinning finish, this product is built to withstand a maximum operating temperature of 105 °C.

For storage, it is designed to endure temperatures between -40 °C and 70 °C, making it a robust choice for various applications Notably, it contains no SVHC in concentrations exceeding 01 wt%, reinforcing its safety profile.

Features and Benefits:

•Compliant with environmental regulations.

•Compatible only with OMNIMATE basic products.

•Designed without breaking capacity according to IEC 61984.

•Long-term storage capability at average temperatures of 50 °C and maximum humidity of 70% for up to 36 months.
