4061230000 - Solid-State Relay 52-72V DC, 0.1A, RoHS Compliant (Pack of 20)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SSS RELAIS, a robust solid-state relay expertly crafted to function with control voltages ranging from 52 V DC to 72 V DC This relay can handle switching voltages between 0 and 48 V DC effortlessly It is engineered to support a continuous current capacity of 01 A and features a convenient plug-in connection for easy installation Designed in compliance with RoHS regulations, this relay operates effectively within a wide temperature range, withstanding conditions from -40 °C to 70 °C, and functioning optimally in ambient temperatures between -20 °C and 60 °C.

Weighing in at just 3425 g, it also boasts impressive technical attributes, including a maximum load voltage drop of no more than 1 V and a minimal leakage current below 10 µA, ensuring reliable performance in various applications.

Features and Benefits:

•Compliant with RoHS standards.

•Designed to withstand a broad temperature range.

•Capable of rapid switching, with a switch-on delay of less than 35 µs.

•Built with a plug-in connection for ease of installation.

Specifications:
