2618920000 - 48V Relay Socket, Single CO Contact, 10A Capacity (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TRP 48VUC 1CO EMPTY relay socket, expertly crafted to handle a control voltage of 48 V UC ±10 % This device is equipped with a single changeover (CO) contact and has the capacity to manage a continuous current of up to 10 A, making it both efficient and reliable With certifications including ROHS compliance and UL certification (file number E223759), this relay ensures high standards of safety and performance.

Designed for ease of use, it features a PUSH IN connection method that simplifies installation Its space-saving design boasts compact dimensions of 878 mm in depth, 894 mm in height, and 64 mm in width, while weighing just 247 g The TRP relay operates effectively in a wide temperature range from -40 °C to 60 °C and accommodates a relative humidity level of 5-95% Additionally, it meets various safety certifications, including a pollution severity level of 2 and a dielectric strength of 4 kV, ensuring long-lasting reliability.

Features and Benefits:

•Designed for a control voltage of 48 V UC ±10 %.

•Compliant with ROHS regulations.

•Includes UL certification.

•Compact design for easy installation.

•Supports a continuous current of 10 A.

Specifications:
