2618430000 - 230VAC Solid-State Relay with Push-In Connections (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TOP 230VAC RC, a reliable solid-state relay engineered for 230 V AC control voltages, with a tolerance range of +5% to -10% This versatile relay supports an impressive switching voltage spectrum between 24 to 240 V AC and can manage a continuous current of up to 1 A Featuring convenient push-in connections, it meets RoHS compliance standards for safety and environmental responsibility.

Designed to operate effectively in temperatures from -20 °C to 60 °C, with the ability to be stored in conditions as extreme as -40 °C to 70 °C, this product is certified under UL file number E141197, ensuring high quality and reliability.

Features and Benefits:

•ROHS compliant.

•Compact design with push-in connections.

•Green LED status indicator.

•Able to accept rigid and flexible copper conductors.

•Short-circuit protection is not provided.

Specifications:
