2618290000 - 60V UC Relay Module with 2 CO Contacts, 8A Capacity (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TRP 60VUC 2CO relay module, featuring two changeover (CO) contacts crafted from high-quality AgNi material This reliable device operates at a control voltage of 60 V UC with a tolerance of ±10%, and can support a continuous current of up to 8 A Utilizing a convenient PUSH IN connection method, this module is designed for ease of installation, although it does not include a test button.

Additionally, it is compliant with RoHS standards, ensuring it meets essential environmental safety guidelines.

Features and Benefits:

•Coil voltage of the replacement relay supports deviations from the rated control voltage.

•Green LED status indicator.

•Rated power capacity is 360 mW and 500 mVA.

•Up to 2000 VA AC switching capacity achievable with a resistive load.

•Operates reliably in a range of temperatures and humid conditions.
