1479800000 - 5VDC Relay Module 1CO, 16A, Compact Design 87.8mm Depth (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TRZ 5VDC 1CO 16A relay module, engineered for reliable performance with a single changeover contact crafted from silver nickel Operating efficiently at a control voltage of 5 V DC ±20 %, this module supports a continuous current capacity of up to 16 A The device features a tension-clamp connection method for secure wiring, although it does not include a test button Adhering to RoHS standards, this relay ensures compliance with environmental regulations.

Measuring 878 mm in depth, 905 mm in height, and 128 mm in width, it is compact and lightweight at just 52 grams It is designed for a wide temperature range, functioning effectively between -40 °C and 60 °C, and can be stored in conditions as low as -40 °C up to 85 °C With a humidity tolerance of 5% to 95% without condensation, this relay module is versatile for various applications.

Features and Benefits:

•Single changeover contact (1 CO contact AgNi).

•Rated control voltage of 5 V DC ±20 %.

•Continuous current of 16 A.

•Tension-clamp connection for easy installation.

•No test button available.

Specifications:
