1127280000 - 12VDC Solid-State Relay with LED, 2A Capacity (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TOZ series solid-state relay, engineered for precise control with a rated input voltage of 12 V DC ±20% It operates efficiently within a voltage range of 3 to 33 V DC, handling a steady current of 2 A Installation is simplified with a tension-clamp connection system This relay is built to endure a broad temperature spectrum, with storage tolerances from -40 °C to 70 °C and operational limits between -20 °C to 60 °C.

It also accommodates humidity levels from 5% to 95% Meeting RoHS compliance standards, it features a reliable rated switching current of 2 A and can manage a peak inrush current of 15 A for brief intervals Additionally, a green LED status indicator allows for instant confirmation of its operational condition, making this relay an excellent choice for your control needs.

Features and Benefits:

•RoHS compliant with exemption.

•Green LED status indicator.

•Tension-clamp connection for easy installation.

•Flexible conductor types supported.

Specifications:
