1127090000 - 0.1A Solid-State Relay, 120V Control, Compact Size (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Presenting the TOZ 120VUC 48VDC0,1A solid-state relay, engineered for a diverse range of applications This unit operates with a control voltage of 120 V UC ±10 % and is capable of switching between 3 to 48 V DC, handling a continuous current of 01 A It is equipped with tension-clamp connections for secure installation and has passed rigorous compliance checks, including a cULus certification (Certificate No.

E141197) With dimensions of 878 mm in depth, 905 mm in height, and a width of 64 mm, this relay has a compact design and weighs just 2728 g It operates effectively within a temperature range of -20 °C to 60 °C and can be stored safely in temperatures from -40 °C to 70 °C, while also managing 5-95% relative humidity without condensation.

Features and Benefits:

•Solid-state relay for reliable operation.

•Lightweight design with net weight of 27.28 g.

•Compliant with RoHS and REACH SVHC regulations.

•Easy wire connection with tension-clamp mechanism.

Specifications:
