1124010000 - 60V UC Relay Socket with 2 CO Contacts, 10A Capacity (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TRS 60VUC 2CO EMPTY relay socket, specially engineered to fulfill targeted operational requirements This component boasts a control voltage rating of 60 V UC ±10%, and is equipped with two CO contacts, ensuring versatile functionality Capable of handling a continuous current of 10 A, it features a secure screw connection for reliable performance Additionally, it meets safety standards, as indicated by its UL file number E223759, assuring you of its quality and compliance.

Features and Benefits:

•Compatible with fixed connection using screw method.

•Capable of operating at an altitude of up to 2000 m.

•Offers a green LED status indicator for operational clarity.

•Constructed with a robust black housing, rated V-0 for flammability.

Specifications:
