1123940000 - 24-230V Relay Module with Green LED, 87.8mm Depth (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TRZ 24-230VUC 2CO AU relay module, a reliable component featuring two contacts that operates effectively within a control voltage range of 24 to 230 V UC ±10 % With a continuous current capacity of 8 A, this module is designed for robust usage The tension-clamp connection provides secure wiring, while the absence of a test button increases its streamlined functionality This module is certified under the cULus standards (certificate number E141197), ensuring its adherence to quality and safety guidelines.

In terms of dimensions, it measures 878 mm in depth, 905 mm in height, and 128 mm in width, with a net weight of 605 g, making it compact and easy to integrate into various applications Designed for versatility, it can withstand storage temperatures from -40 °C to 85 °C and operate in ambient conditions up to 40 °C The module also complies with RoHS and identifies lead as an SVHC according to REACH regulations, underlining its environmentally-friendly design.

With a maximum switching frequency of 01 Hz at rated loads and a convenient green LED indicator for operational status, this relay module is an excellent choice for your control solutions.

Features and Benefits:

•Two CO contacts with gold-plated AgNi.

•Rated control voltage of 24...230 V UC ±10 %.

•Simple tension-clamp connection method.

•Green LED status indicator.

Specifications:
