1123030000 - 60V UC Relay Module with Gold-Plated Contacts, 6A Capacity (Pack of 10)

1123030000 - 60V UC Relay Module with Gold-Plated Contacts, 6A Capacity (Pack of 10)

SKU: SKU: 1123030000   Download PDF

Select a Variant:
  • 1123030000 - 60V UC Relay Module with Gold-Plated Contacts, 6A Capacity (Pack of 10)
Qty:
Regular price Now $175.33   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $175.33 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the TRS 60VUC 1CO AU relay module, a reliable solution featuring a single normally open contact composed of gold-plated silver nickel Designed for a control voltage of 60 V UC, it operates efficiently within a tolerance of ±10% and supports a continuous current capacity of up to 6 A The module is equipped with a screw connection for secure installation and does not include a test button, making it an excellent choice for various applications.

Features and Benefits:

    •Gold-plated contact for reliable performance.

    •No test button feature.

    •Screw connection method.

Specifications:

 Order No. 1123030000
 Depth 87.8 mm
 Height 89.6 mm
 Width 6.4 mm
 Storage temperature -40 °C...85 °C
 Ambient temperature -40 °C...60 °C
 Rated current AC 4.8 mA
 Rated current DC 2.8 mA
 Power rating 170 mW
 Coil voltage of the replacement relay 60 V DC
 Rated switching voltage 250 V AC
 Continuous current 6 A
 Max. switching frequency at rated load 0.1 Hz
 Switch-on delay ≤ 7 ms
 Switch-off delay ≤ 50 ms
 Contact type 1 CO contact (AgNi gold-plated)
 Mechanical service life 5 x 10^6 switching cycles
 Operating altitude ≤ 2000 m above sea level
 Rated voltage 300 V
 Insulation coordination reinforced insulation
 Protection degree IP20
 Wire connection method Screw connection
 Clamping range, rated connection 1.5 mm²
 Clamping range, min. 0.14 mm²
 Clamping range, max. 2.5 mm²
