1121990000 - Black IP65 FieldPower Enclosure, 181mm x 223mm x 42mm (Pack of 10)
1121990000 - Black IP65 FieldPower Enclosure, 181mm x 223mm x 42mm (Pack of 10)
SKU: SKU: 1121990000 Download PDF
- 1121990000 - Black IP65 FieldPower Enclosure, 181mm x 223mm x 42mm (Pack of 10)
- 1121990000 - Black IP65 FieldPower Enclosure, 181mm x 223mm x 42mm (Pack of 10)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Introducing the FieldPower enclosures, expertly designed for durability and protection Measuring 181 mm in height, 223 mm in width, and 42 mm in depth, these enclosures offer top-notch IP65 rated protection Crafted from high-quality glass-fibre reinforced polycarbonate, they come in an elegant black finish, making them both functional and stylish Perfect for various applications, these enclosures ensure your equipment remains safe from dust and moisture.
Features and Benefits:
•IP65 protection degree.
•Constructed from glass-fibre reinforced polycarbonate.
•Screw mounting type.
•Includes cable gland.
Specifications:
| Depth | 42 mm |
| Width | 223 mm |
| Height | 181 mm |
| Net weight | 367 g |
| Storage temperature | -40 °C...85 °C |
| Operating temperature | -20 °C...80 °C |
| Protection degree | IP65 |
| RoHS Compliance Status | Compliant without exemption |
| Cable gland clamping area, max | 12 mm |
| Cable gland clamping area, min | 6 mm |
| Cable gland material | Polyamide 6 |
| Number of cable glands | 4 |
| Basic material | Polycarbonate, glass fibre reinforced |
| Enclosure material | glass-fibre reinforced polycarbonate |
| UL 94 flammability rating | 5VA |
| Fixing lugs | With cable gland |
