8074760000 - 12V AC Relay with 4 Contacts, 29mm Deep, Plug-in Design (Pack of 10)

Description:

Introducing the Riderseries RCM570512 relay, designed for reliability and efficiency This model boasts four silver nickel changeover contacts and operates at a control voltage of 12 V AC, with a continuous current capacity of 6 A Featuring a plug-in connection along with a convenient test button, this relay is practical for various applications Please be aware that this product will be discontinued after a specified date, but orders can still be placed until 30.

062026 Its compact dimensions measure 29 mm in depth, 28 mm in height, and 225 mm in width, weighing just 30 g, making it easy to integrate into your setup The relay performs exceptionally well in storage temperatures ranging between -40 °C and 85 °C, while functioning optimally in ambient conditions of -40 °C to 70 °C, with a humidity tolerance of 93% (non-condensing) Furthermore, it adheres to RoHS regulations, ensuring it does not include any substances of very high concern exceeding 0.

1 wt% On the control side, it features a rated control voltage of 12 V AC, a current rating of 833 mA, and a power rating of 1000 mVA The maximum switching voltage is 250 V AC, with various inrush and switching current specifications supporting diverse operational needs.

Features and Benefits:

•Co contact made of AgNi.

•Plug-in connection.

•Mechanical switch position indicator.

•Lockable test button.

•Momentary test button.

•Protection degree IP20.

Specifications:
