2905360000 - Orange PA 66 Female Connector, 8mm Diameter, 35mm² Capacity (Pack of 5)

Description:

Introducing the WBC-P-8OR-35, a robust connection solution that complies with various safety regulations, including RoHS standards, and has been certified by UL (File Number E529699) Crafted primarily from PA 66 material, this connector boasts a vibrant orange color and is designed for versatility It can accommodate a maximum conductor cross-section of 35 mm², featuring a male contact diameter of 8 mm.

The cable has an outer diameter measuring between 106 mm and 113 mm, making it suitable for various applications With a continuous operating temperature range of -40 °C to 125 °C, it is built to perform in diverse environmental conditions, including areas with humidity levels up to 85% RH Moreover, this female connector utilizes a reliable crimp connection type and is rated for a nominal current of 150 A and a nominal voltage of 1,500 V.

It is also marked as RoHS compliant and does not contain any REACH SVHC above 01 wt% Choose the WBC-P-8OR-35 for a dependable and efficient connection solution.

Features and Benefits:

•UL 4128 approved.

•RoHS compliant without exemption.

•Shock resistance V2.

•IP67 protection degree when plugged.

•Capable of ≥100 plugging cycles.

•Vibration resistance of 30g.

•V-0 UL 94 flammability rating.

Specifications:
