2663030000 - TRP Relay Socket 24-230V, 10A, Compact 87.8mm Depth (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TRP 24-230VUC 1CO EMPTY ED2 relay socket, an essential component for efficient control of electrical circuits This relay socket accommodates control voltages between 24 and 230 V UC ±10% and is equipped with a single CO contact, allowing for a continuous current capacity of 10 A Built to withstand harsh conditions, this relay is certified for RoHS compliance and operates effectively in temperatures ranging from -40 °C to 60 °C.

Compact yet robust, it measures 878 mm in depth, 894 mm in height, and 64 mm in width, with a lightweight design of just 31 grams Perfect for various applications where reliability is crucial.

Features and Benefits:

•Supports a continuous current of 10 A.

•Rated control voltage from 24 to 230 V UC ±10 %.

•One CO contact.

•Depth of 87.8 mm, height of 89.4 mm, and width of 6.4 mm.

•Net weight of 31 g.

•Operating altitude up to 2000 m.

•Wire connection method is PUSH IN.

•Environmental rating of IP20.

Specifications:
