1127250000 - Solid-State Relay 24-230V, 2A DC Switching能力 (Pack of 10)

1127250000 - Solid-State Relay 24-230V, 2A DC Switching能力 (Pack of 10)

SKU: SKU: 1127250000   Download PDF

Select a Variant:
  • 1127250000 - Solid-State Relay 24-230V, 2A DC Switching能力 (Pack of 10)
Qty:
Regular price Now $450.36   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $450.36 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Experience reliable control with the TOS 24-230VUC solid-state relay, crafted for voltage inputs ranging from 24 to 230 V UC, with a ±10% tolerance This versatile relay can effectively switch from 3 to 33 V DC and operates with a continuous current of 2 A Designed for ease of installation, it includes a secure screw connection and adheres to ROHS standards, confirming its commitment to environmental responsibility.

Features and Benefits:

    •Compliant with ROHS regulations.

    •Screw connection type for easy mounting.

    •Continuous current rating of 2 A for reliable performance.

    •Designed for both rigid and flexible copper conductors.

Specifications:

 Rated control voltage 24…230 V UC ±10 %
 Rated switching voltage 3...33 V DC
 Continuous current 2 A
 Ambient temperature (operational), max. 40 °C
 Control side nominal control current 22 mA @ 24 V DC, 4 mA @ 230 V AC
 Power rating 530 mW @ 24 V DC, 930 mVA @ 230 V AC
 Inrush current 15 A / 10 ms
 Switch-on delay <20 ms
 Switch-off delay <100 ms
 Net weight 34 g
 Depth 87.8 mm
 Height 89.6 mm
 Width 6.4 mm
 UL94 flammability rating V-0
 Protection degree IP20
