1126990000 - 230V Solid-State Relay, 48V DC, 0.1A, UL Certified (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TOS 230VUC 48VDC01A solid-state relay, engineered for reliability with a control voltage of 230 V UC ±10% Capable of switching voltages between 3 to 48 V DC, this relay boasts a continuous current capability of 01 A It features easy-to-use screw connections and comes with a UL certification (cULus) number E141197, ensuring safety and compliance Meeting RoHS standards, this product is part of the TERMSERIES and is readily available for order.

It operates efficiently in temperatures ranging from -20 °C to 60 °C and can be stored in environments from -40 °C to 70 °C.

Features and Benefits:

•Rated control voltage of 230 V UC ±10%.

•Rated switching voltage from 3 to 48 V DC.

•Continuous current capacity of 0.1 A.

•Includes a green LED status indicator.

•Insulation coordination with a rated voltage of 300 V.

•IP20 protection degree.

Specifications:
