1123730000 - 24VDC Relay Module with 2 Gold-Plated Contacts, 8A Capacity (Pack of 10)

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the TRS 24VDC 2CO AU relay module, featuring dual changeover (CO) contacts that are gold-plated with AgNi for enhanced conductivity Operating on a control voltage of 24 V DC, this relay maintains a tolerance of ±20% It can handle continuous currents of up to 8 A and includes a reliable screw connection for secure installation Please note that this model does not include a test button Engineered to meet RoHS standards, this versatile module is capable of functioning in diverse environmental conditions, boasting a storage temperature range of -40 °C to 85 °C and an operational range of -40 °C to 60 °C.

This relay module is ideal for a wide array of applications, particularly for managing circuits with specific load needs.

Features and Benefits:

•2 CO contacts with AgNi gold plating.

•Continuous current rating of 8 A.

•Rated control voltage of 24 V DC ±20 %.

•Screw connection wiring method.

Specifications:
