2913740000 - 5-Pole PCB Terminal Connector, 5mm Pitch, RoHS Compliant (Pack of 20)
2913740000 - 5-Pole PCB Terminal Connector, 5mm Pitch, RoHS Compliant (Pack of 20)
SKU: SKU: 2913740000 Download PDF
- 2913740000 - 5-Pole PCB Terminal Connector, 5mm Pitch, RoHS Compliant (Pack of 20)
- 2913740000 - 5-Pole PCB Terminal Connector, 5mm Pitch, RoHS Compliant (Pack of 20)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Discover the MTS 5/05 V T4 B T terminal, expertly crafted for THT solder connections This printed circuit board terminal boasts a 500 mm pitch and supports 5 poles It meets essential regulatory standards, including RoHS compliance, ensuring safety and environmental responsibility With an impressive IEC rating of 400 V at 32 A and a UL rating of 300 V at 185 A, this terminal is built for reliability.
Supplied in convenient tubes, it comes with comprehensive specifications that outline dimensions, electrical capabilities, and installation guidelines.
Features and Benefits:
•Compliant with RoHS standards.
•SNAP IN wire connection with push button.
•Easy to install with THT solder connection.
•Touch-safe according to DIN VDE 0470, protected from finger contact.
Specifications:
| Depth (mm) | 13.2 |
| Height (mm) | 22.35 |
| Width (mm) | 27.3 |
| Ambient temperature | -50 °C to 80 °C |
| Installation temperature | -50 °C to 70 °C |
| Rated current | 32 A |
| Rated voltage | 400 V |
| Clamping range, min. | 0.34 mm² |
| Clamping range, max. | 4 mm² |
| Solder pin length | 3.5 mm |
| Pitch | 5 mm |
| Protection degree | IP20 |
| Material | PA 9T |
