2913720000 - 5mm Pitch Terminal Block Board, 3 Poles, ROHS Compliant (Pack of 31)
2913720000 - 5mm Pitch Terminal Block Board, 3 Poles, ROHS Compliant (Pack of 31)
SKU: SKU: 2913720000 Download PDF
- 2913720000 - 5mm Pitch Terminal Block Board, 3 Poles, ROHS Compliant (Pack of 31)
- 2913720000 - 5mm Pitch Terminal Block Board, 3 Poles, ROHS Compliant (Pack of 31)
Couldn't load pickup availability
*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color
Description:
Discover the functionality of this printed circuit board terminal, featuring THT solder connections arranged with a 500 mm pitch Packaged in a convenient tube, it consists of 3 poles and meets ROHS compliance standards Additionally, it comes with UL certification, identified by number E60693, ensuring its quality and reliability for your electronic projects.
Features and Benefits:
•Available in tube packaging.
•Compliant with ROHS without exemption.
•Conforms to environmental product standards.
Specifications:
| Number of poles | 3 |
| Rated voltage (IEC) | 400 V / 300 V |
| Rated current (IEC) | 32 A / 18.5 A |
| Depth | 13.2 mm |
| Height | 22.35 mm |
| Width | 17.3 mm |
| Operating temperature | -50 °C to 80 °C |
| Storage temperature | -25 °C to 55 °C |
| Clamping range | 0.34 mm² to 4 mm² |
| Contact material | Cu-alloy |
| Insulating material | PA 9T |
| IP protection degree | IP20 |
