2812570250 - 2.5m Shielded M12 Sensor Cable with 4 Poles and LED

2812570250 - 2.5m Shielded M12 Sensor Cable with 4 Poles and LED

SKU: SKU: 2812570250   Download PDF

Select a Variant:
  • 2812570250 - 2.5m Shielded M12 Sensor Cable with 4 Poles and LED
Qty:
Regular price Now $18.60   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $18.60 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the SAIL-M12GM12G-4-3LR25TOV, an integral part of our sensor and actuator collection This device boasts a generous cable length of 25 meters, featuring a straight pin to straight socket connection With four poles and a shielded design, it's built for reliability Crafted from durable PUR material, this cable includes LED functionality and adheres to halogen-free standards, making it a responsible choice for various applications.

Features and Benefits:

    •LED functionality.

    •Compliant with RoHS exemptions.

    •Resistant to welding sparks.

    •Suitable for cable carriers.

    •LABS-free.

Specifications:

 Cable length 2.5 m
 Core cross-section 0.34 mm²
 Nominal current 4 A
 Nominal voltage 250 V
 Bending cycles 10 Mio
 Protection degree IP65, IP66, IP67, IP68 when screwed in
 Temperature range, moving -25...80 °C
 Temperature range, stationary -40...80 °C
 Outside diameter 4.9 mm ± 0.2 mm
 Connection thread M12 / M12
 Contact surface Gold-plated
 Bending radius, min., moving 7.5 x cable diameter
 Bending radius, min., stationary 4 x cable diameter
 Sheath material PUR
 Number of poles 4
