9457770040 - M12 to M8 Connection Line, 0.4m, PUR Sheath

9457770040 - M12 to M8 Connection Line, 0.4m, PUR Sheath

SKU: SKU: 9457770040   Download PDF

Select a Variant:
  • 9457770040 - M12 to M8 Connection Line, 0.4m, PUR Sheath
Qty:
Regular price Now $10.45   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $10.45 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a versatile connection line tailored for sensor and actuator uses This configuration features an M12 to M8 connection with a length of 04 meters It includes three poles arranged in a straight pin/socket design, ensuring straightforward connectivity The line is made from robust PUR material and is free from halogens, though it does not come with shielding or an LED Perfect for reliable applications where quality matters.

Features and Benefits:

    •3 poles with a non-shielded design.

    •Sheath material made of PUR.

    •Hydrolysis and microbe resistant.

    •Temperature range for moving applications is -25 to 60 °C.

    •Suitable for cable carriers.

    •Plug left is M12, A-coded, IP69, male contact, straight, Plastic, unshielded.

    •Plug right is M8, IP69, female contact, straight, Plastic, LED, unshielded.

Specifications:

 Diameter 3.6 mm
 Cable length 0.4 m
 Core cross-section 0.25 mm²
 Nominal current 4 A
 Nominal voltage 60 V
 Insulation resistance 10^8 Ω
 Protection degree IP69, IP65, IP66
 Bending radius, min., moving 10 x cable diameter
 Bending radius, min., stationary 5 x cable diameter
 Speed 3.33 m/s
 Temperature range, stationary -50...80 °C
 Plugging cycles ≥ 100
