9457810470 - 4.7m Unshielded 3-Pole Sensor/Actuator Line, PUR Sheath

9457810470 - 4.7m Unshielded 3-Pole Sensor/Actuator Line, PUR Sheath

SKU: SKU: 9457810470

Variant:
  • 9457810470 - 4.7m Unshielded 3-Pole Sensor/Actuator Line, PUR Sheath
Regular price Now $9.49
Regular price BEFORE   $0.00 Sale price Now $9.49
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover this advanced sensor/actuator cable, measuring 47 meters in length with a reliable 3-pole setup One end of the cable is free of connectors, while its 38 mm diameter ensures easy handling and flexibility Constructed from halogen-free PUR sheath material, this unshielded cable is designed for versatility and durability, making it an excellent choice for various applications.

Features and Benefits:

    •Compliant with RoHS exemption.

    •Hydrolysis and microbe resistant.

    •LABS-free.

    •Suitable for moving applications.

Specifications:

 Diameter 3.8 mm
 Cable length 4.7 m
 Core cross-section 0.34 mm²
 Nominal current 4 A
 Nominal voltage 250 V
 Insulation resistance 10^8 Ω
 Protection degree IP65, IP66, IP67, IP68, IP69
 Temperature range, moving -25...60 °C
 Temperature range, stationary -50...80 °C
 Speed 3.33 m/s
 Bending cycles 12 Mio
 Bending radius, min., moving 10 x cable diameter
 Bending radius, min., stationary 5 x cable diameter
