2681530000 - M12 Field Attachable Connector, 4A, IP67, -40°C to 85°C

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Discover the versatility of this field-mountable M12 connector, expertly engineered to meet RoHS standards and boasting cULus certification It supports cable diameters from 4 mm to 8 mm and is equipped with male contacts With a nominal current rating of 4 A and a voltage capacity of 60 V, this connector is built to deliver reliable performance Constructed from durable PA 66 material, it features a robust diecast zinc threaded ring.

Its housing is temperature resistant, functioning effectively between -40 °C and +85 °C while providing IP67-rated protection against dust and water Additionally, this connector is designed to withstand shock and vibration in accordance with the EN 50155:2001 standards, ensuring longevity and stability in various environments.

Features and Benefits:

•Compliance with RoHS without exemptions.

•Insulation resistance of >= 100 MΩ.

•A-coded connector for reliable connection.

•Can connect cables with a minimum cross-section of 0.14 mm² up to a maximum of 0.75 mm².

•Protection against dust and water with IP67 rating.

•PUSH IN type connection ensures easy usability.

•Resistant to shocks and vibrations per relevant standards.
