1927310300 - 3m M12/M8 Sensor Line with 3 Poles, PVC Sheath

1927310300 - 3m M12/M8 Sensor Line with 3 Poles, PVC Sheath

SKU: SKU: 1927310300

Select a Variant:
  • 1927310300 - 3m M12/M8 Sensor Line with 3 Poles, PVC Sheath
Qty:
Regular price Now $6.93   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $6.93 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing a versatile sensor/actuator line that features a unique design with one end left without a connector This product is equipped with M12 and M8 connectors, offering three poles and an impressive length of 3 meters The cable is crafted from durable PVC material for the sheath, ensuring reliable performance Please note that this model does not include shielding or an LED indicator Perfect for your various connectivity needs!.

Features and Benefits:

    •Not shielded.

    •LED not included.

    •Made of PVC.

    •Halogen-free.

    •Weight of 88g.

    •A-coded connection thread.

    •Nominal current rated at 4A.

    •Nominal voltage rated at 60V.

    •Plug cycles greater than or equal to 100.

    •Temperature range for moving applications: -5 to 80 °C.

    •Temperature range for stationary applications: -30 to 80 °C.

    •IP65, IP66, IP67, IP68 rated when screwed in.

Specifications:

 Cable length 3 m
 Number of poles 3
 Outer diameter 4.5 mm ± 0.2 mm
 Sheath material PVC
 Insulation resistance 10^8 Ω
 Nominal current 4 A
 Nominal voltage 60 V
 Protection degree IP65, IP66, IP67, IP68
 Temperature range of housing -25 to +85 °C
 Connection thread M12 / M8
 Core cross-section 0.25 mm²
 Coding A-coded
