1890521500 - 15m Shielded Sensor/Actuator Line with 8 Poles

1890521500 - 15m Shielded Sensor/Actuator Line with 8 Poles

SKU: SKU: 1890521500

Variant:
  • 1890521500 - 15m Shielded Sensor/Actuator Line with 8 Poles
Regular price Now $61.73
Regular price BEFORE   $0.00 Sale price Now $61.73
Sold out
IN STOCK
Shipping Available
Free shipping on orders above $1000.* Only on standard purchases of cables and wires.
View full details
Product Information

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing a versatile 15-meter sensor/actuator line that boasts a female socket in a streamlined design This line features eight poles and is shielded for enhanced durability Constructed from high-quality PUR material, it adheres to RoHS standards and relevant exemptions for safety Please note that this product does not include an LED.

Features and Benefits:

    •Shielded design.

    •No LED included.

    •Halogen-free sheath material.

    •Compliant with RoHS.

Specifications:

 Cable length 15 m
 Sheath material PUR
 Number of poles 8
 Outside diameter 6.3 mm ± 0.2 mm
 Temperature range, moving -25...80 °C
 Temperature range, stationary -40...80 °C
 Nominal current 2 A
 Nominal voltage 30 V
 Protection degree IP67 when screwed in, IP65, IP66
 Plugging cycles ≥ 100
 Insulation resistance 10^8 Ω
 Bending cycles 1 million
 Connection thread M12
 Gold-plated contact surface Yes
