1890520200 - 2m 8-Pole Shielded Sensor/Actuator Line, Halogen-Free

1890520200 - 2m 8-Pole Shielded Sensor/Actuator Line, Halogen-Free

SKU: SKU: 1890520200

Select a Variant:
  • 1890520200 - 2m 8-Pole Shielded Sensor/Actuator Line, Halogen-Free
Qty:
Regular price Now $27.81   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $27.81 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing an essential component from our sensor/actuator line, this product features a 2-meter long cable with a female socket at one end, designed for easy integration It boasts an 8-pole configuration and is crafted with a highly protective PUR sheath, ensuring durability Additionally, the design is free from halogens, making it a safe choice for various applications Please note, this model does not include an LED indicator for status monitoring.

Features and Benefits:

    •Shielded construction for enhanced protection.

    •Female socket configuration for easy connection.

    •Flexible sheath material made of PUR.

    •Temperature resistance ranging from -40 to +80 °C.

    •Compatible with M12 connection thread.

    •Gold-plated contact surface for reliability.

    •Able to withstand high-speed operations up to 100 m/s.

Specifications:

 Cable length 2 m
 Number of poles 8
 Outside diameter 6.3 mm ± 0.2 mm
 Protection degree IP67 when screwed in
 Nominal current 2 A
 Nominal voltage 30 V
 Insulation resistance 10^8 Ω
 Bending radius, min., moving 12 x cable diameter
 Bending radius, min., stationary 5 x cable diameter
 Core cross-section 0.25 mm²
 Weight 105.6 g
 Sheath colour black
 Coding A-coded
