1716820000 - White 9x6mm Terminal Marker for Woertz Systems (Pack of 400)

1716820000 - White 9x6mm Terminal Marker for Woertz Systems (Pack of 400)

SKU: 1716820000   Download PDF

Select a Variant:
  • 1716820000 - White 9x6mm Terminal Marker for Woertz Systems (Pack of 400)
Qty:
Now $33.71   Web pricing policy
BEFORE   $0.00 Now $33.71 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information Resources Reviews
Product Information

Description:

Introducing the MF-WO 9/6 MC NE WS terminal marker, a reliable component specifically designed for Woertz systems With compact dimensions of 9 x 6 mm and a pitch of 600 mm, this marker is crafted from durable Polyamide 66 in a versatile white color It fully complies with RoHS regulations without any exemptions, ensuring an environmentally friendly choice This product remains stable even in a broad temperature range, functioning effectively between -40 to 100 °C.

Each MultiCard conveniently holds one terminal marker, making it compatible with the PRINTJET CONNECT printer Additionally, it boasts a UL 94 flammability rating of V-2, ensuring safety in various applications.

Features and Benefits:

    •RoHS compliant without exemption.

    •Compatible with PRINTJET CONNECT printer.

    •Made from Polyamide 66.

    •Stable across a temperature range of -40 to 100 °C.

    •Stable material color according to resistance code.

    •UL 94 flammability rating of V-2.

    •Use in Woertz systems for terminal marking.

Specifications:

 Height 9 mm
 Width 6 mm
 Operating temperature range -40...100 °C
 Basic material Polyamide 66
 Number of markers per combination 1 MultiCard = Terminal marker
 Cradle to gate 0.001 kg CO2 eq.
 Printed characters neutral
 Type of printing neutral
 Dimensions and weights {'Height (inches)': '0.354 inch', 'Width (inches)': '0.236 inch', 'Net weight': '0.255 g'}
 Pitch in mm (P) 6 mm
 ETIM classifications {'ETIM 6.0': 'EC000761', 'ETIM 7.0': 'EC000761', 'ETIM 8.0': 'EC000761', 'ETIM 9.0': 'EC000761', 'ETIM 10.0': 'EC000761'}
 ECLASS classifications {'ECLASS 9.0': '27-14-11-37', 'ECLASS 10.0': '27-14-11-37', 'ECLASS 11.0': '27-28-11-01', 'ECLASS 12.0': '27-28-11-01', 'ECLASS 13.0': '27-28-11-01', 'ECLASS 14.0': '27-28-11-01', 'ECLASS 15.0': '27-28-11-01'}
