1555380500 - 5m Non-Shielded M8 8-Pole Sensor Line with Angled Socket

1555380500 - 5m Non-Shielded M8 8-Pole Sensor Line with Angled Socket

SKU: SKU: 1555380500

Select a Variant:
  • 1555380500 - 5m Non-Shielded M8 8-Pole Sensor Line with Angled Socket
Qty:
Regular price Now $24.75   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $24.75 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Introducing the SAIL-M8BW-8-50U sensor/actuator line, designed for efficiency and versatility This model features a robust M8 connector with 8 poles and a generous length of 5 meters It is equipped with an angled socket and is non-shielded, offering a streamlined design without an LED indicator Constructed from durable PUR sheath material, this product is also halogen-free, ensuring safety and longevity.

Perfect for industrial applications where reliable performance is key.

Features and Benefits:

    •Approvals: RoHS compliant with exemptions.

    •Bending radius minimum for moving conditions is 10 times the diameter of the cable.

    •Bending radius minimum for stationary conditions is 5 times the diameter of the cable.

    •Insulation material is PP.

    •Speed rating is 5 m/s.

    •Suitable for use with cable carriers.

    •Coding is A-coded.

Specifications:

 Cable Length 5 m
 Number of Poles 8
 Outer Diameter 5.9 mm ± 0.2 mm
 Nominal Current 2 A
 Nominal Voltage 30 V
 Temperature Range (Moving) -25...80 °C
 Temperature Range (Stationary) -40...80 °C
 Protection Degree IP67 when screwed in, IP65, IP66
 Contact Surface Gold-plated
 Housing Material PUR
 Weight 236 g
