1424280500 - 5m Shielded Sensor/Actuator Line with 12 Poles, Angled Socket

1424280500 - 5m Shielded Sensor/Actuator Line with 12 Poles, Angled Socket

SKU: SKU: 1424280500   Download PDF

Select a Variant:
  • 1424280500 - 5m Shielded Sensor/Actuator Line with 12 Poles, Angled Socket
Qty:
Regular price Now $42.81   Web pricing policy
Regular price BEFORE   $0.00 Sale price Now $42.81 Web pricing policy
Sold out
Shipping calculated at checkout.
IN STOCK
Shipping Available
Free shipping on orders above $1000. *Wires and cables only.
View full details
Product Information

Description:

Discover this advanced sensor/actuator unit, expertly designed with a connector-free end for seamless integration Boasting 12 poles and a generous length of 5 meters, it features an angled and shielded socket, ensuring reliable performance Crafted from PUR material, this product is also free from halogens, making it a safe choice for various applications.

Features and Benefits:

    •Compliant with RoHS standards.

    •Connection thread type is M12.

    •Suitable for use in cable carriers.

    •Shielded design.

Specifications:

 Acceleration 5 m/s²
 Bending cycles 1 million
 Bending radius, min., moving 12 x cable diameter
 Bending radius, min., stationary 5 x cable diameter
 Cable length 5 m
 Core cross-section 0.14 mm²
 Insulation PP
 Number of poles 12
 Sheath material PUR
 Speed 100 m/s
 Temperature range, moving -30...90 °C
 Temperature range, stationary -40...90 °C
 Nominal current 1.5 A
 Nominal voltage 30 V
 Protection degree IP67 when screwed in
 Threaded ring material Diecast zinc
 Connector standard IEC 61076-2-101
