1392710000 - Four-Pole T-Connection Feed-Through Connector, 60V Rated

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing the SAIS-WDF-4-M20-T-COD, a versatile panel feed-through connector designed for T-connection This connector comes with four poles and supports a maximum nominal voltage of 60 V Engineered for flexibility, it serves a variety of electrical applications and can be customized to meet specific requirements Additionally, it boasts UL certification for safety compliance and meets RoHS standards, ensuring environmentally friendly use.

Features and Benefits:

•Compliant with RoHS standards.

•UL certified with certificate number E307231.

•Connection type is screw connection.

•Protection degree is IP67.

•Able to withstand a temperature range from -40 to +85 °C.

•Gold-plated contact surface ensures reliable electrical connection.

•High insulation resistance of 10^8 Ω.

•Capable of handling plugging cycles of 100 or more.

Specifications:
