1292140150 - 1.5m Unshielded Sensor/Actuator Line with 4-Pole Female Socket

*Data provided on this page is subject to change based on different manufacturers' variances
** Images are for display purposes only refer to Product Technical Details for accurate information on the product.
In the case the material only comes in a predetermined color or doesn’t come with any color

Description:

Introducing this versatile female socket, designed for sensor and actuator applications Measuring 15 meters in length and featuring four poles (three plus PE), it provides reliable connectivity This unshielded model has a straight configuration and is crafted from PUR material, ensuring it is halogen-free for safer use Order number 1292140150 and GTIN (EAN) 4050118087895 provide easy reference for this essential component.

Features and Benefits:

•Bending cycles rated at 5 million.

•Minimum bending radius is 7.5 times the cable diameter.

•Cable length of 1.5 meters.

•Quattro color coding: brown, white, blue, black.

•No option for configurable cable length.

•Core cross-section of 1.5 mm².

•TPM insulation material.

•Outer cladding compliant with UL AWM style.

•Outside diameter measures 8 mm ± 0.2 mm.

•Suitable for cable carriers.

•Temperature range while moving is -20 to 80 °C.

•Temperature range when stationary is -50 to 80 °C.

•Plugging cycles of at least 100 times.

•Rated impulse voltage is 2,500 V.

•Protection degree rated IP68 when screwed in.

•Rated voltage according to UL is 600 V.

•Temperature range of housing from -40 to +85 °C.

Specifications:
